HIKVISION 16-ch 1080p 1U H.265 AcuSense Digital Video Recorder (DVR)

$1,988.00

Availability: Only 2 left in stock

Introducing the (iDS-7216HQHI-M1/S) HIKVISION 16-ch 1080p 1U H.265 AcuSense Digital Video Recorder, a cutting-edge solution for your surveillance needs. This DVR offers support for up to 16 channels of high-definition video recording, ensuring comprehensive coverage for your property. Equipped with H.265 compression technology, it allows for efficient storage of footage without compromising on quality. With AcuSense technology, the DVR can accurately detect and distinguish between humans and vehicles, reducing false alarms and enhancing security. Its compact 1U design makes it suitable for various environments, while its user-friendly interface allows for easy setup and operation.

General Specifications:

– 16 channels and 1 HDD 1U AcuSense DVR
– False alarm reduction through human and vehicle target classification based on deep learning
– Efficient H.265 pro+ compression technology
– Encoding ability up to 3K/5M Lite @ 12 fps
– 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
– Up to 24 network cameras can be connected.

Technical Specifications:

Motion Detection 2.0 : Human/Vehicle Analysis –Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;

Perimeter Protection: Human/Vehicle Analysis – Up to 4-ch

Facial Detection And Capture: Face picture detection, face picture search

Recording:
Video Compression
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264

Frame Rate:
Main stream:

When 1080p Lite mode not enabled:

For 3K stream access: 3K lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps

For 5 MP stream access: 5 MP lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps

For 4 MP stream access: 4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

When 1080p Lite mode enabled:

3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

Sub-stream:

WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)

Stream Type: Video, Video & Audio

Video & Audio:

IP Video Input: 2-ch (up to 18-ch); Up to 6 MP resolution

Enhanced IP mode on: 8-ch (up to 24-ch), each up to 4 Mbps;Support H.265+/H.265/H.264+/H.264 IP cameras

Analog Video Input: 16-ch;BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

HDMI Output: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

CVBS Input: PAL/NTSC

CVBS Output: 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480

Audio Output: 1-ch, RCA (Linear, 1 KΩ)

Audio Input: 1-ch, RCA (2.0 Vp-p, 1 KΩ),16-ch via coaxial cable;1

Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)

Network:
Total Bandwidth: 128 Mbps
Network Protocol: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Remote Connection: 128
Network Interface: 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface

Auxiliary Interface:
SATA: 1 SATA interface
Capacity: Up to 10 TB capacity for each disk
Serial Interface: RS-485 (half-duplex)
USB Interface: 1 × USB 2.0; 1 × USB 3.0



Weight 5 lbs
